OVERVIEW:
Dell™ PowerConnect™ 6200 offers advanced switching capabilities including Power Over Ethernet (PoE), high-density, high-performance stacking and 10 Gigabit Ethernet capabilities scalable from the small business to the Enterprise Edge.
FEATURES:
• With 24 or 48 built-in copper Gigabit Ethernet ports in a 1U form factor, as well as a 24 port Fiber GbE version for backbone or long-haul connectivity, the PowerConnect 6200 series gives users the flexibility to maximize server and workstation connectivity in a 1U form factor. The switches also offer support up to four 10 Gigabit Ethernet uplinks for connectivity directly to 10GbE servers, enterprise backbones and distributed campus wiring closets (IDF and MDF).
• High-performance stacking with 10GbE: The PowerConnect 6200 series supports highperformance resilient stacking for up to twelve systems and almost 2 Terabits of capacity in a single stack (each switch supports up to 184 Gbps in switch capacity). The unique modular design allows you to upgrade to advanced stacking or 10 Gigabit Ethernet only when you need it. Plus the 6200 series offers further flexibility with optional modules that allow for either 10 Gigabit copper interfaces, or both. The optional stacking interfaces allow for high availability stacking with sub-100ms failover times, even in the event of a master unit failure.
• Advanced switching features with robust security: The PowerConnect 6200 series supports advanced Layer 3 routing and multicast protocols to help reduce congestion and manage traffic in the network. The PowerConnect 6200 series supports frequently used LAN routing protocols such as RIPv1/v2, OSPFv2/v3, VRRP, IGMP v1/v2/v3, DVMRP, PIM and LLDP-MED. The PowerConnect 6200 offers flexibility in Quality of Service (QoS) by giving network administrators the ability to prioritize time-critical Layer 2 or Layer 3 network traffic.
Support for L2-L4 Access Control Lists (ACLs) on the switch allows the user to perform deep packet inspection. 802.1x port authentication offers both single and multiple host access. Further security is provided through Denial of Service (DoS) Attack Prevention, whereby the switch can protect against common network attacks. PowerConnect 6200 switches are IPv6 ready.
• Power Over Ethernet (PoE) support: The PowerConnect 6200 series PoE switches offer PoE-per-port support for power-dependent network applications including WLAN Access Points (WAPs), Voice over IP (VoIP) handsets, video conferencing and badge reading. The 6224P and 6248P switches can provide up to 15.4 watts of power for networkattached devices.

Dell PowerConnect 6224 24-port Gigabit Switch

Texas Depot

OVERVIEW:
The HP J9028B ProCurve 1800-24G is a 24-port, 1U height, web-managed Gigabit Ethernet switch with 22 auto-sensing 10/100/1000 Mbps ports and two dual-personality ports that can be used as either RJ-45 or SFP/mini-GBIC. Key specifications include a 48 Gbps switching capacity, an 8000-entry MAC address table, and support for key protocols like VLANs, LACP, and QoS. It features a fanless design for silent operation and a web-based management interface.
FEATURES:
[ CONNECTIVITY ]
• Jumbo packet support: To improve performance of large data transfers
[ RESILIENCY AND HIGH AVAILABILITY ]
• IEEE 802.3ad Link Aggregation Control Protocol (LACP): Provides link-level redundancy with support for up to 4 trunks onthe HPE ProCurve Switch 1800-8G and 12 trunks on the HPE ProCurve Switch 1800-24G, each with up to 8 links (Ports) per trunk
[ LAYER 2 SWITCHING ]
• VLAN Support and tagging: Support up to 64 port-based VLANs and dynamic configuration of IEEE 802.1Q VLAN tagging, providing security between workgroups
[ SECURITY ]
• Management password: Provides security so that only authorized access to the Web browser interface is allowed
[ QUALITY OF SERVICE (QoS) ]
• Traffic prioritization: Honors priority of traffic based on 802.1p to deliver data to devices based on the priority and type of traffic
• Broadcast control: Allows limitation of broadcast traffic rate to cut down on unwanted broadcast traffic on the network
[ MANAGEABILITY ]
• Intuitive Web interface: Enables simple management via an easy-to-use Web browser interface for switch configuration, monitoring, and administration
• Integration with ProCurve Manager: Enables discovery and mapping via ProCurve Manager, available as a free download from the Web
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP): Automated device discovery protocol for easy mapping by network management applications
[ MONITOR AND DIAGNOSTICS ]
• Port mirroring: Enables traffic on a port to be simultaneously sent to a network analyzer for monitoring
[ EASE OF USE ]
• Comprehensive LED display with per-port indicators: Provides an at-a-glance view of status, activity, speed, and full-duplex operation
• ProCurve/IEEE Auto-MDIX: Automatically adjusts for straight-through or crossover cables on all 10/100/1000 ports
[ FLEXIBILITY ]
• Small form factor: Ideal for desktop use; space-efficient for deployment flexibility (1800-8G only)
• Designed with no fan: Enables quiet operation for deployment in open spaces

HP J9028B ProCurve 1800-24G Gigabit Switch

OVERVIEW:
The HP 2810 Switch Series consists of two switches: the 24-port HP 2810-24G Switch with 20 10/100/1000 ports, and the 48-port HP 2810-48G Switch with 44 10/100/1000 ports. Each switch also has four dual-personality ports for RJ-45 10/100/1000 or mini-GBIC fiber Gigabit connectivity. Ideal for high-performance and secure 10/100/1000 connectivity, the 2810 switch series offers access security and advanced prioritization and traffic-monitoring capabilities. The series is cost-effective and easy to use, with a shallow, 1U form factor that provides operational flexibility for use in smaller wiring closets.
FEATURES:
[ KEY FEATURES ]
• Managed Layer 2 feature set with 24 or 48 Gb ports
• sFlow, source port filtering, enhanced security
• Optional redundant power supply
• Four dual-personality mini-GBIC slots
[ CONNECTIVITY ]
• Dual-personality functionality: Four 10/100/1000 ports or SFP slots for optional fiber connectivity such as Gigabit-SX, -LX, -LH, or 100-FX.
[ RESILENCY AND HIGH AVAILABILITY ]
• IEEE 802.3ad Link Aggregation Protocol (LACP) and HP trunking: Supports up to 24 trunks, each with up to 8 links (ports) per trunk.
• IEEE 802.1s Multiple Spanning Tree: Provides high link availability in multiple VLAN environments by allowing multiple spanning trees; provides legacy support for IEEE 802.1d and IEEE 802.1w.
• Optional redundant power supply: Provides uninterrupted power (Provided by HP 600 RPS/EPS).
[ LAYER 2 SWITCHING ]
• VLAN support and tagging: Supports the IEEE 802.1Q (4,096 VLAN IDs) and 256 VLANs simultaneously.
• GARP VLAN Registration Protocol: Allows automatic learning and dynamic assignment of VLANs.
• Jumbo packet support: Supports up to 9,224-byte frame size to improve performance of large data transfers.
[ SECURITY ]
• Port security: Allows access only to specified MAC addresses, which can be learned or specified by the administrator.
• Protected ports: Provides increased security by allowing specified ports to be isolated from all other ports on the switch; the protected port or ports can only communicate with the uplink or shared resources.
• MAC address lockout: Prevents configured particular MAC addresses from connecting to the network.
• Multiple user authentication methods:
- IEEE 802.1X: Industry-standard method of user authentication using an IEEE 802.1X supplicant on the client in conjunction with a RADIUS server.
- Web-based authentication: Similar to IEEE 802.1X, provides a browser-based environment to authenticate clients that do not support the IEEE 802.1X supplicant.
- MAC-based authentication: Client is authenticated with the RADIUS server based on client's MAC address.
• Switch management logon security: Can require either RADIUS or TACACS+ authentication for secure switch CLI logon.
• Multiple IEEE 802.1X users per port: Provides authentication of up to two IEEE 802.1X users per port; prevents user "piggybacking" on another user's IEEE 802.1X authentication.
• STP BPDU port protection: Blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks.
• Secure FTP: Allows secure file transfer to/from the switch; protects against unwanted file downloads or unauthorized copying of switch configuration file.
• RADIUS/TACACS+: Eases switch management security administration by using a password authentication server.
• Source-port filtering: Allows only specified ports to communicate with each other.
• Secure Shell (SSHv2): Encrypts all transmitted data for secure, remote command-line interface (CLI) access over IP networks.
• Secure Sockets Layer (SSL): Encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch.
[ CONVERGENCE ]
• IP Multicast snooping and data-driven IGMP: Automatically prevents flooding of IP multicast traffic.
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP): Automated device discovery protocol for easy mapping by network management applications
• Per-port broadcast throttling: Selectively configure broadcast control on heavy traffic port uplinks
• Software updates: Free downloads from the Web
[ QUALITY OF SERVICE (QoS) ]
• Traffic prioritization (IEEE 802.1p): Allows real-time traffic classification into eight priority levels mapped to eight queues.
• Class of Service (CoS): Sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), L3 protocol, TCP/UDP port number, source port, and DiffServ.
• Layer 4 prioritization: Enables prioritization based on TCP/UDP port numbers.
[ MANAGEABILITY ]
• sFlow (RFC 3176): Wire-speed traffic accounting and monitoring
• RMON: Provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events.
• Dual flash images: Provides independent primary and secondary operating system files for backup while upgrading.
• Troubleshooting: Ingress/egress port monitoring enables network problem-solving
• Single IP address management: Single IP address management for a virtual stack of up to 16 switches
• Multiple configuration files: Allow multiple config files to be stored to flash image
[ EASE OF USE ]
• Locator LED: Allows users to set the locator LED on a specific switch to either turn On, blink, or turn Off; simplifies troubleshooting by making it easy to locate a particular switch within a rack of similar switches.
• Friendly port names: Allow assignment of descriptive names to ports.
• Find-Fix-and-Inform: Finds and fixes common network problems automatically, then informs administrator.
• HP/IEEE Auto-MDIX: Automatically adjusts for straight-through or crossover cables on all RJ-45 ports.
